A Studio Layout Checklist to Work Through Before You Commit

Start with the shows, not the room

Most layout problems begin when a room is measured before anyone has written down what will happen in it. Before you look at a floor plan, list every programme the studio will carry: the morning bulletin, the evening live show, the occasional two-way with a reporter on location. Each one asks something different of the floor. A single-presenter bulletin needs one desk and a clean background, while a live show with guests may need a sofa area, a standing position and room for a roaming camera.

Write down who is in the room during each programme: presenters, guests, camera operators, floor manager, any runner. Then note who needs to cross the floor while the studio is live, and who should never be seen doing so. That short list will tell you more about the right layout than any brochure, because it shows where people meet, and meeting points are where crews end up getting in each other's way.

• Which programmes will use the floor, and how often
• How many people are physically present for each
• Who must move while the studio is on air

Check the floor itself

Walk the empty room and look at it as a working surface. Measure the clear height to the lowest obstruction, because a pedestal camera, a lighting grid and a boom all compete for the same vertical space. Note where the doors are, which ones open into the studio, and whether any of them lets in light or noise from corridors. A door that swings across the main camera track will cause trouble every single day.

Look at the floor material too. Pedestal cameras need a smooth, level surface to move without bumps showing in the picture, and joins, ramps or old cable trunking can quietly ruin a smooth track. If the floor is not flat, find out now whether it can be levelled or whether the camera positions have to be planned around it. It is far cheaper to decide this on paper than after the first rehearsal.

• Clear height to the lowest fixed obstruction
• Floor flatness along every planned camera track
• Door positions, swing direction and daylight leaks

Fix the positions that everything else follows

Three things anchor a studio layout: the presenter position, the main camera angles and the background. Settle these first, and let lighting, sound and cabling follow from them. A common mistake is to place the desk where it looks good in an empty room, and only then discover that the cameras have no room to stand back, or that the background is lit by a window the crew cannot cover.

Draw the camera positions with their full travel, not as small dots. A pedestal needs room to turn, a robotic head needs a clear line of sight to every mark, and the operator needs space behind the camera. Mark where each presenter looks, and check that no camera, monitor or crew member sits in that eye line. Walk through one full rehearsal on the drawing before anything is moved on the real floor.

• Presenter, desk and background placed before anything else
• Camera travel drawn in full, including turning space
• Eye lines kept clear of monitors and crew

Plan the cable routes early

Cabling is the part of a layout that nobody photographs and everyone trips over. Decide where the studio's connection points sit, which runs go under a floor or along a wall, and which have to cross open floor at all. Where a cable must cross a camera track, plan a protected crossing and keep it away from the places where pedestals turn.

Separate the types of cable as well. Power, audio, video and intercom lines do better when they run apart, and labelling both ends of every run saves a surprising amount of time when something fails during a live broadcast. Leave spare capacity in the routes you choose. A studio that is fully packed on day one has nowhere to grow when a new camera or an extra monitor is added next year.

• Connection points and fixed routes agreed before equipment arrives
• Power kept apart from audio and video where possible
• Both ends of every run labelled, with spare capacity left

Think about the crew's day

A layout should be judged by how it feels at the third hour of a long shift, not at the first walkthrough. Look at how operators reach their cameras, where the floor manager stands to see both the presenter and the director's cues, and how a guest is brought in without crossing a live shot. Give the crew a path that works in the dark between segments, when the lights are down and the floor is busy.

Think also about safety and access. Exits must stay clear, equipment must be reachable for maintenance, and nobody should need to climb over something to change a lamp or swap a microphone. If you expect more than one programme to share the room, consider which parts of the set can be moved and how long a changeover will really take. A layout that needs an hour to reset will not suit a short gap between shows.

• Paths for crew and guests that avoid live shots
• Floor manager position with a view of presenter and cues
• Realistic changeover time between programmes

Questions to answer before you decide

Once the drawing exists, test it against a few plain questions. Can every camera see its marks without anyone standing in the way? Can a cable fail and be replaced without stopping the broadcast? Could a new operator find their way round on a first day? If any answer is uncertain, the layout is not finished, and it is better to say so now than to discover it with the lights on.

It also helps to have someone outside the project read the drawing. A person who has not been part of the planning will notice the awkward doorway, the missing crossing or the monitor blocking an eye line within minutes. Treat their comments as part of the checklist, and only commit to equipment orders and installation dates once the plan has survived that last review.
